sound generator
|
piano sound
|
PureAcoustic Piano Modeling
|
Highest chord
|
Piano: Unrestricted (solo use of voices 1 to 8 in the piano category) Others: 256
|
tone
|
Piano: 20 tones E. Piano: 18 notes Organ: 18-tone Strings/Pads: 27 notes Synthesizer/Others: 279 sounds (including 8 drum sets, 1 SFX set)
|
environment
|
Pure sound environment
|
Type: studio, lounge, concert hall, wooden hall, stone hall, cathedral Depth: 11 types
|
my stage
|
my stage
|
12 kinds
|
keyboard
|
keyboard
|
PHA-50 Keyboard: Hybrid wood and plastic construction with escapement and ebony/ivory feel (88 keys)
|
speaker system
|
Speaker
|
Speakers: 8 x 12 cm (3-3/16 x 4-3/4 inches) x 2 (with speaker box) Dome tweeter: 2.5cm (1in) x 2
|
Rated output power
|
25 watts x 2 5 watts x 2
|
headphones
|
headphones
|
headphone acoustic projection
|
Bluetooth
|
news
|
Bluetooth version 3.0 (supports SCMS-T content protection)
|
MIDI
|
Bluetooth version 4.0
|
Compatible Android/iOS App (Roland)
|
Compatible Android/iOS App (Roland) |
piano every day piano designer
|
data playback
|
Playable software
|
Standard MIDI files (formats 0, 1) Audio files (WAV: 44.1 kHz, 16-bit linear format, MP3: 44.1 kHz, 64 kbps-320 kbps, USB flash drive required)
|
recorder
|
Recording software
|
Standard MIDI file (format 0, 3 parts, approximately 70,000 note storage) Audio file (WAV: 44.1 kHz, 16-bit linear format, USB flash drive required)
|
internal song
|
internal song
|
34 songs
|
to tune, to pronounce
|
Touch sensitivity
|
Key strength: 100 types, fixed strength Hammer response: 10 types
|
main tune
|
415.3--466.2 Hz (adjustable in 0.1 Hz increments)
|
temperament
|
10 types (Equal, Median, Median, Pythagorean, Kornberg I, Kornberg II, Kornberg III, Meantone, Werckmeister, Arabic), optional temperament keys |
special effects
|
atmosphere Equalizer (3-band digital equalizer) For organ sounds only: Rotating speaker effect For E. Piano Voices only: modulation speed
|
microphone effect
|
compressor double echo
|
piano designer
|
build key off noise hammer noise Double sided scale full scale column resonance emphatically deviate from resonance Box resonance sound board type Damper noise Soft pedal type monotone tuning Single tone volume Single tone characters
|
Convenient features
|
Convenient features
|
Metronome (tempo/beat/downbeat/mode/volume/pitch) automatic speed Transpose (Keyboard/Song: Semitone) Registrations (45 registrations, pedal shifting available) Registration settings double Split (split point is adjustable) double piano Sound demo automatic shutdown
|
other
|
show
|
Graphic LCD 132 x 32 dots
|
control
|
Volume slider EQ slider (low/mid/high) sound Bottom slider (down/up) Song volume. slider Microphone volume slider speaker switch Microphone gain knob
|
Connector
|
DC In jack Pedal (Damper/R, Sostenuto/C*1, Soft/L*1) Jack: TRS 1/4 inch phone type Input Stereo Jack: Stereo Microphone Type Output (L/Mono, R) Jack: 1/4 inch phone type Microphone input jack: 1/4-inch phone type USB computer port: USB Type B USB storage port: USB A type Telephone jack x 2: Stereo mini phone type, Stereo 1/4 inch phone type MIDI (output, input) interface *1: Assignable
|
power supply
|
AC adapter
|
energy consumption
|
40W (when using the included AC adapter) *Approximate power consumption when playing piano at medium volume: 14W Power consumption when no sound is played after power on: 12W
|
accessories
|
accessories
|
User manual manual "Safe to use" AC adapter power cable music stand Damper pedal (DP-10, continuous detection)
|
Options (sold separately)
|
Options (sold separately)
|
Special bracket: KSC-90 Special pedal board: KPD-90 Keyboard stand: KS-G8B, KS-10Z, KS-12, KS-20X Pedal unit: RPU-3 Shock absorbing pedal: DP series Pedal switch: DP-2 (*1) Expression pedal: EV-5 Bag: CB-88RL earphone
*1 Cannot be used with Damper/R.
|
Dimensions and weight
|
Dimensions
|
Separate music stand: 1,340(W)x390(D)x136(H)mm 52-13/16(W) x 15-3/8(D) x 5-3/8(H) inches
FP-90X KSC-90 and Music Stand: 1,340 (W) x 418 (D) x 932 (H) mm 52-13/16(W) x 16-1/2(D) x 36-3/4(H) inches
|
weight
|
23.6 kg, 52 lbs 1 oz (FP-90X with music stand) 37.8 kg, 83 lbs 6 oz (FP-90X with KSC-90, KPD-90 and music stand)
|
